Final Project Initial Planning

Final Project: Group Brainstorming


  • 2 actions

    • Music as action – speaker

    • Light turning on as action

    • Simple movement in box

    • Shadow box: light turns on to reveal something in box

      • Inside box??

      • Flying dutchman degrading

      • Light related mythology

      • Diwali:

      • Diwali is the “victory of good over evil, light over darkness”. In the story, the demon ravana is defeated, we could have a sensor that senses light and when it is dark the demon lights up and when lights are on the demon disappears to represent light beating dark

      • arms and heads can move (this image is also in the public domain so it’s free to use—we can trace this to laser cut)

  • Materials:

    • 1/8th inch plywood

    • Leds

    • Cardstock

    • Wood stain

    • vinyl plastic?

    • Acrylic paint

    • Fiber optics

    • Photodetector

    • prototyping board

    • 5 volt NeoPixel

    • Power source is 5 volts supplied to us

  • Sensor:

    • light sensor

  • Themes

    • Mythology?

    • Rock

    • Bugs - hex bug?

      • Mantis type puppet

    • Alien-like movement

    • Mimic chest – looks like a monster
